[Minebea-intec] Indicator Weight transmitter CSD-892

Description

The weight transmitter CSD-892 processes weight values from silo and vessel scales quickly and reliably with analogue load cells

Features

Configurable display for greater ease of use

Time-saving configuration

Connectivity for an easy data transfer

Basic dosing possible without additional programming effort

Model

PR 5220

Material

IP Protection

Resolution

Standard Interface

Weight transmitters CSD-892

Space-saving installation on DIN top hat rails.

Space-saving, reliable and user friendly

Built-in control panel and display
The display can be individually adapted for configuration and status indication.

Simple configuration via USB/display
The EzCTS software allows an easy configuration with the possibility to save and to print the
parameter set.

Including integrated RS-422/485 interface
An ASCII character based protocol transmits the data on request or via data stream.

Simple one-component dosing
One-component filling with control outputs for coarse, medium and fine dosing.
